Synthetic · filterable
No solids. Filterable, and runs clear for inspection. For kilns, ball mills, dryers and pelletisers.
3,260 / 5,202 / 15,500 cSt @ 40 °C · weld 620 kg
Super Heavy >800 kg · suitable down to −7 °C
On approval list: Metso Minerals (Heavy). Qualified, Metso Table 2: Metso:Outotec (Heavy).
| Property | Value |
|---|---|
| Type | Synthetic open-gear lubricant (light gold) |
| Grades / viscosity | Gold ISO 3200 3,260 / Heavy 5,202 / Super Heavy 15,500 cSt @ 40 °C |
| Load / behaviour | 4-ball weld 620 kg (>800 kg Super Heavy) · no solids, filterable |
| Low temperature limit | Suitable down to −7 °C |
Figures are from the Whitmore document set of 2 June 2026, pending datasheet checks. Confirm against current Whitmore TDS at quote.
| OEM | Grade | Basis | Dated |
|---|---|---|---|
| Metso Minerals | Heavy | approval list | 2016 |
| Metso:Outotec | Heavy | qualified (Metso Table 2) | 2021 |
Each row names its basis. Sources: Whitmore data sheets, whitmores.com pages, Metso:Outotec document 3-21-003 (Table 2), and Whitmore's OEM approvals register of 17 June 2026.
| Product | Type | Notes |
|---|---|---|
| Envirolube® XE Extreme | Non-asphaltic high-viscosity fluid | FZG 0.067 mg/kWh · −8 °C to 111 °C |
| GearMate® 1000 ICT | Lithium open-gear grease, five grades | TCLP-safe · usable low −40 °C (Arctic) |
| SurStik® 800 | Aluminium-complex open-gear grease | Weld 800 kg · −43 °C to 121 °C by grade |
| BMG-6000 | Synthetic open-gear grease (surface repair) | Surface repair · pump and spray from −4 °C |
| MillGuard™ | High-viscosity petroleum-resin fluid | TDS on request |
| Surtac® 2000 | Multiservice lubricant, bentonite | TDS on request |
