Lithium grease · five grades
Lithium open-gear grease in five grades, Arctic to Super Heavy. TCLP-safe and non-emulsifying.
Five grades · 1,900–6,500 cSt @ 40 °C · 4-ball weld 800 kg
Usable low −40 °C (Arctic) · TCLP-safe
Approved by email: Outotec. Meets specification: Caterpillar SD 4713 (Super Heavy, shovel hoist drum gears). Approved (PDS): PRASA (Heavy).
| Property | Value |
|---|---|
| Type | Lithium open-gear grease (black, non-transparent) |
| Grades / viscosity | Arctic 000 / All-Season 00 / Light 0-00 / Heavy 0 / Super Heavy 0-1 · 1,900–6,500 cSt @ 40 °C |
| Load / behaviour | 4-ball weld 800 kg · TCLP-safe · non-emulsifying |
| Usable low temperature | −40 °C (Arctic) to −1 °C (Super Heavy), by grade |
Figures are from the Whitmore document set of 2 June 2026, pending datasheet checks. Confirm against current Whitmore TDS at quote.
| OEM | Grade | Basis | Dated |
|---|---|---|---|
| Outotec | — | approved by email | 2016 |
| Caterpillar SD 4713 | Super Heavy, shovel hoist drum gears | meets specification | 2011 |
| PRASA | Heavy | approved (PDS) | — |
Each row names its basis. Sources: Whitmore data sheets, whitmores.com pages, Metso:Outotec document 3-21-003 (Table 2), and Whitmore's OEM approvals register of 17 June 2026.
| Product | Type | Notes |
|---|---|---|
| Envirolube® XE Extreme | Non-asphaltic high-viscosity fluid | FZG 0.067 mg/kWh · −8 °C to 111 °C |
| Decathlon® Gold | Synthetic open-gear lubricant | Weld 620 kg (>800 Super Heavy) · down to −7 °C |
| SurStik® 800 | Aluminium-complex open-gear grease | Weld 800 kg · −43 °C to 121 °C by grade |
| BMG-6000 | Synthetic open-gear grease (surface repair) | Surface repair · pump and spray from −4 °C |
| MillGuard™ | High-viscosity petroleum-resin fluid | TDS on request |
| Surtac® 2000 | Multiservice lubricant, bentonite | TDS on request |
