Multiservice · Arctic / Medium / Heavy
Aluminium-complex grease. A tenacious film that resists wash-off on draglines, shovels and mills.
1,520 / 2,620 / 4,380 cSt @ 40 °C · 4-ball weld 800 kg
On approval list: Bucyrus SD 4713 (Arctic · Medium · Heavy) · Bucyrus blast-hole drill OGL. Approved by email: Outotec. Meets specification: P&H #520 · P&H Spec 464. Meets specification or approved (PDS): Komatsu · IHI (Japan) · PRASA (South Africa).
| Property | Value |
|---|---|
| Type | Aluminium-complex open-gear grease (black) |
| Grades / viscosity | Arctic 1,520 / Medium 000 2,620 / Heavy 0 4,380 cSt @ 40 °C |
| Load / behaviour | 4-ball weld 800 kg · tenacious film, wash-off resistant |
| Service temperature | −43 °C to 121 °C (by grade) |
Figures are from the Whitmore document set of 2 June 2026, pending datasheet checks. Confirm against current Whitmore TDS at quote.
| OEM | Grade | Basis | Dated |
|---|---|---|---|
| Bucyrus SD 4713 | Arctic · Medium · Heavy | approval list | — |
| Bucyrus blast-hole drill OGL | — | approval list | — |
| Outotec | — | approved by email | 2016 |
| P&H #520 | — | meets specification | — |
| P&H Spec 464 | — | meets specification | — |
| Komatsu | — | meets specification or approved (PDS) | — |
| IHI (Japan) | — | meets specification or approved (PDS) | — |
| PRASA (South Africa) | — | meets specification or approved (PDS) | — |
Each row names its basis. Sources: Whitmore data sheets, whitmores.com pages, Metso:Outotec document 3-21-003 (Table 2), and Whitmore's OEM approvals register of 17 June 2026.
| Product | Type | Notes |
|---|---|---|
| Envirolube® XE Extreme | Non-asphaltic high-viscosity fluid | FZG 0.067 mg/kWh · −8 °C to 111 °C |
| Decathlon® Gold | Synthetic open-gear lubricant | Weld 620 kg (>800 Super Heavy) · down to −7 °C |
| GearMate® 1000 ICT | Lithium open-gear grease, five grades | TCLP-safe · usable low −40 °C (Arctic) |
| BMG-6000 | Synthetic open-gear grease (surface repair) | Surface repair · pump and spray from −4 °C |
| MillGuard™ | High-viscosity petroleum-resin fluid | TDS on request |
| Surtac® 2000 | Multiservice lubricant, bentonite | TDS on request |
